Note: If you are not sure about Frame Relay theory, please read my Frame Relay tutorial first. In fact the DLCIs in the topology are not very logical, especially DLCIs 304 & 403 for the links between R1 & R2, but well… let’s configure them. First we will configure the Frame Relay switch with the DLCIs shown above. We will use a router (R5) to simulate the Frame Relay switch instead of using a Frame Relay Switch in GNS3.
+ All routers must be able to ping themselves.
+ Configure point-to-point subinterface on R2 & R3. + Configure static mappings on R1 and R4. The logical and physical topologies of this lab are shown below: In this lab we will try to run a Frame Relay topology same as the one posted in TSHOOT demo ticket.
